Re: Dockstar HW mod: Trying to add native sata November 18, 2021 03:19PM |
Admin Registered: 13 years ago Posts: 18,821 |
> MiB Mem : 235.9 total, >
Re: Dockstar HW mod: Trying to add native sata November 18, 2021 07:53PM |
Registered: 2 years ago Posts: 56 |
console=ttyS0,115200 earlyprintk=serial ignore_loglevel memblock=debug initcall_debug bootmem_debug root=LABEL=rootfs rootdelay=1 orion_nand:1M(u-boot),4M(uImage),32M(rootfs),-(data)(data)
SoC: Kirkwood 88F6281_A0 DRAM: 64 MiB WARNING: Caches not enabled NAND: 256 MiB In: serial Out: serial Err: serial Net: egiga0 88E1116 Initialized on egiga0 Hit any key to stop autoboot: 0 starting USB... USB0: USB EHCI 1.00 scanning bus 0 for devices... 3 USB Device(s) found scanning usb for storage devices... Use USB retry period from the environment: 15 second(s) 1 Storage Device(s) found Reset IDE: ide_preinit failed Partition Map for USB device 0 -- Partition Type: DOS Part Start Sector Num Sectors UUID Type 1 53817344 20969472 e9df59ed-01 83 Boot 2 74788864 1048576 e9df59ed-02 82 3 75837440 900933632 e9df59ed-03 83 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 loading envs from usb 0 ... ** File not found /boot/uEnv.txt ** no IDE devices available running scan_disk ... Scan device usb device usb 0:1 1 bytes read in 723 ms (0 Bytes/s) Found bootable drive on usb 0 loading uImage ... 5435888 bytes read in 1004 ms (5.2 MiB/s) loading uInitrd ... 9671091 bytes read in 967 ms (9.5 MiB/s) loading DTB /boot/dts/kirkwood-goflexnet.dtb ... 11457 bytes read in 1768 ms (5.9 KiB/s) ## Booting kernel from Legacy Image at 00800000 ... Image Name: Linux-5.13.6-kirkwood-tld-1 Created: 2021-09-24 0:22:58 UTC Image Type: ARM Linux Kernel Image (uncompressed) Data Size: 5435824 Bytes = 5.2 MiB Load Address: 00008000 Entry Point: 00008000 Verifying Checksum ... OK ## Loading init Ramdisk from Legacy Image at 01100000 ... Image Name: initramfs-5.13.6-kirkwood-tld-1 Created: 2021-09-24 1:06:32 UTC Image Type: ARM Linux RAMDisk Image (gzip compressed) Data Size: 9671027 Bytes = 9.2 MiB Load Address: 00000000 Entry Point: 00000000 Verifying Checksum ... OK ## Flattened Device Tree blob at 01c00000 Booting using the fdt blob at 0x1c00000 Loading Kernel Image ... OK Loading Ramdisk to 031d4000, end 03b0d173 ... OK Loading Device Tree to 031ce000, end 031d3cc0 ... OK Starting kernel ... Uncompressing Linux... done, booting the kernel.(Dies there)
U-Boot 2017.07-tld-1 (Sep 05 2017 - 00:17:19 -0700) Seagate GoFlex Net SoC: Kirkwood 88F6281_A0 DRAM: 128 MiB WARNING: Caches not enabled NAND: 256 MiB In: serial Out: serial Err: serial Net: egiga0 88E1116 Initialized on egiga0 Hit any key to stop autoboot: 0 starting USB... USB0: USB EHCI 1.00 scanning bus 0 for devices... 3 USB Device(s) found scanning usb for storage devices... Use USB retry period from the environment: 15 second(s) 1 Storage Device(s) found Reset IDE: ide_preinit failed Partition Map for USB device 0 -- Partition Type: DOS Part Start Sector Num Sectors UUID Type 1 53817344 20969472 e9df59ed-01 83 Boot 2 74788864 1048576 e9df59ed-02 82 3 75837440 900933632 e9df59ed-03 83 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 loading envs from usb 0 ... ** File not found /boot/uEnv.txt ** no IDE devices available running scan_disk ... Scan device usb device usb 0:1 1 bytes read in 723 ms (0 Bytes/s) Found bootable drive on usb 0 loading uImage ... 5435888 bytes read in 1004 ms (5.2 MiB/s) loading uInitrd ... 9671091 bytes read in 966 ms (9.5 MiB/s) loading DTB /boot/dts/kirkwood-goflexnet.dtb ... 11457 bytes read in 1769 ms (5.9 KiB/s) ## Booting kernel from Legacy Image at 00800000 ... Image Name: Linux-5.13.6-kirkwood-tld-1 Created: 2021-09-24 0:22:58 UTC Image Type: ARM Linux Kernel Image (uncompressed) Data Size: 5435824 Bytes = 5.2 MiB Load Address: 00008000 Entry Point: 00008000 Verifying Checksum ... OK ## Loading init Ramdisk from Legacy Image at 01100000 ... Image Name: initramfs-5.13.6-kirkwood-tld-1 Created: 2021-09-24 1:06:32 UTC Image Type: ARM Linux RAMDisk Image (gzip compressed) Data Size: 9671027 Bytes = 9.2 MiB Load Address: 00000000 Entry Point: 00000000 Verifying Checksum ... OK ## Flattened Device Tree blob at 01c00000 Booting using the fdt blob at 0x1c00000 Loading Kernel Image ... OK Loading Ramdisk to 071d4000, end 07b0d173 ... OK Loading Device Tree to 071ce000, end 071d3cc0 ... OK Starting kernel ... Uncompressing Linux... done, booting the kernel. [ 0.000000][ T0] Booting Linux on physical CPU 0x0 [ 0.000000][ T0] Linux version 5.13.6-kirkwood-tld-1 (root@tldDebian) (gcc (Debian 8.3.0-6) 8.3.0, GNU ld (GNU Binutils for Debian) 2.31.1) #1.0 PREEMPT Sat Jul 31 22:10:39 PDT 2021 [ 0.000000][ T0] CPU: Feroceon 88FR131 [56251311] revision 1 (ARMv5TE), cr=0005397f [ 0.000000][ T0] CPU: VIVT data cache, VIVT instruction cache [ 0.000000][ T0] OF: fdt: Machine model: Seagate GoFlex Net [ 0.000000][ T0] Memory policy: Data cache writeback [ 0.000000][ T0] Zone ranges: [ 0.000000][ T0] Normal [mem 0x0000000000000000-0x0000000007ffffff] [ 0.000000][ T0] Movable zone start for each node [ 0.000000][ T0] Early memory node ranges [ 0.000000][ T0] node 0: [mem 0x0000000000000000-0x0000000007ffffff] [ 0.000000][ T0] Initmem setup node 0 [mem 0x0000000000000000-0x0000000007ffffff] [ 0.000000][ T0] Built 1 zonelists, mobility grouping on. Total pages: 32512 [ 0.000000][ T0] Kernel command line: console=ttyS0,115200 root=LABEL=rootfs rootdelay=10 mtdparts=orion_nand:1M(u-boot),4M(uImage),32M(rootfs),-(data) [ 0.000000][ T0] Dentry cache hash table entries: 16384 (order: 4, 65536 bytes, linear) [ 0.000000][ T0] Inode-cache hash table entries: 8192 (order: 3, 32768 bytes, linear) [ 0.000000][ T0] mem auto-init: stack:off, heap alloc:on, heap free:off [ 0.000000][ T0] Memory: 101104K/131072K available (11264K kernel code, 1553K rwdata, 4272K rodata, 1024K init, 309K bss, 29968K reserved, 0K cma-reserved) [ 0.000000][ T0] random: get_random_u32 called from ____cache_alloc+0x408/0x7b4 with crng_init=0 [ 0.000000][ T0] trace event string verifier disabled [ 0.000000][ T0] rcu: Preemptible hierarchical RCU implementation. [ 0.000000][ T0] Trampoline variant of Tasks RCU enabled. [ 0.000000][ T0] Tracing variant of Tasks RCU enabled. [ 0.000000][ T0] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies. [ 0.000000][ T0] NR_IRQS: 16, nr_irqs: 16, preallocated irqs: 16 [ 0.000000][ T0] clocksource: orion_clocksource: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 9556302233 ns [ 0.000002][ T0] sched_clock: 32 bits at 200MHz, resolution 5ns, wraps every 10737418237ns [ 0.000056][ T0] Switching to timer-based delay loop, resolution 5ns [ 0.000852][ T0] Console: colour dummy device 80x30 [ 0.000927][ T0] Calibrating delay loop (skipped), value calculated using timer frequency.. 400.00 BogoMIPS (lpj=2000000) [ 0.000969][ T0] pid_max: default: 32768 minimum: 301 [ 0.001341][ T0] LSM: Security Framework initializing [ 0.001513][ T0] Mount-cache hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 0.001561][ T0] Mountpoint-cache hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 0.002962][ T0] CPU: Testing write buffer coherency: ok [ 0.005449][ T1] Setting up static identity map for 0x100000 - 0x100058 [ 0.005742][ T1] mvebu-soc-id: MVEBU SoC ID=0x6281, Rev=0x2 [ 0.006096][ T1] rcu: Hierarchical SRCU implementation. [ 0.007485][ T1] devtmpfs: initialized [ 0.013353][ T1] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns [ 0.013409][ T1] futex hash table entries: 256 (order: -1, 3072 bytes, linear) [ 0.043493][ T1] prandom32: self test passed (less than 6 bits correlated) [ 0.043538][ T1] prandom: seed boundary self test passed [ 0.046910][ T1] prandom: 100 self tests passed [ 0.046928][ T1] pinctrl core: initialized pinctrl subsystem [ 0.048510][ T1] NET: Registered protocol family 16 [ 0.049375][ T1] DMA: preallocated 256 KiB pool for atomic coherent allocations [ 0.050389][ T1] audit: initializing netlink subsys (disabled) [ 0.051818][ T1] thermal_sys: Registered thermal governor 'step_wise' [ 0.052204][ T16] audit: type=2000 audit(0.050:1): state=initialized audit_enabled=0 res=1 [ 0.052365][ T1] cpuidle: using governor ladder [ 0.052465][ T1] cpuidle: using governor menu [ 0.052934][ T1] Feroceon L2: Enabling L2 [ 0.052986][ T1] Feroceon L2: Cache support initialised. [ 0.060759][ T1] No ATAGs? [ 2.560062][ C0] random: fast init done [ 3.970468][ T39] "cryptomgr_test" (39) uses obsolete ecb(arc4) skcipher [ 3.993577][ T59] wait_for_initramfs() called before rootfs_initcalls [ 4.180298][ T1] raid6: int32x8 gen() 134 MB/s [ 4.350217][ T1] raid6: int32x8 xor() 86 MB/s [ 4.520211][ T1] raid6: int32x4 gen() 136 MB/s [ 4.690147][ T1] raid6: int32x4 xor() 89 MB/s [ 4.860139][ T1] raid6: int32x2 gen() 175 MB/s [ 5.030148][ T1] raid6: int32x2 xor() 106 MB/s [ 5.200268][ T1] raid6: int32x1 gen() 123 MB/s [ 5.370092][ T1] raid6: int32x1 xor() 74 MB/s [ 5.370107][ T1] raid6: using algorithm int32x2 gen() 175 MB/s [ 5.370118][ T1] raid6: .... xor() 106 MB/s, rmw enabled [ 5.370128][ T1] raid6: using intx1 recovery algorithm [ 5.370379][ T1] vgaarb: loaded [ 5.370911][ T1] SCSI subsystem initialized [ 5.371395][ T1] usbcore: registered new interface driver usbfs [ 5.371472][ T1] usbcore: registered new interface driver hub [ 5.371523][ T1] usbcore: registered new device driver usb [ 5.371711][ T1] pps_core: LinuxPPS API ver. 1 registered [ 5.371725][ T1] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it> [ 5.371766][ T1] PTP clock support registered [ 5.373444][ T1] clocksource: Switched to clocksource orion_clocksource [ 5.464121][ T1] VFS: Disk quotas dquot_6.6.0 [ 5.464227][ T1] VFS: Dquot-cache hash table entries: 1024 (order 0, 4096 bytes) [ 5.477527][ T1] NET: Registered protocol family 2 [ 5.477696][ T1] IP idents hash table entries: 2048 (order: 2, 16384 bytes, linear) [ 5.478564][ T1] tcp_listen_portaddr_hash hash table entries: 512 (order: 0, 4096 bytes, linear) [ 5.478616][ T1] TCP established hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 5.478649][ T1] TCP bind hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 5.478676][ T1] TCP: Hash tables configured (established 1024 bind 1024) [ 5.478924][ T1] MPTCP token hash table entries: 512 (order: 0, 6144 bytes, linear) [ 5.478998][ T1] UDP hash table entries: 256 (order: 0, 4096 bytes, linear) [ 5.479035][ T1] UDP-Lite hash table entries: 256 (order: 0, 4096 bytes, linear) [ 5.479245][ T1] NET: Registered protocol family 1 [ 5.484058][ T1] RPC: Registered named UNIX socket transport module. [ 5.484081][ T1] RPC: Registered udp transport module. [ 5.484091][ T1] RPC: Registered tcp transport module. [ 5.484101][ T1] RPC: Registered tcp NFSv4.1 backchannel transport module. [ 5.484117][ T1] PCI: CLS 0 bytes, default 32 [ 5.484287][ T1] NetWinder Floating Point Emulator V0.97 (double precision) [ 5.493793][ T58] Trying to unpack rootfs image as initramfs... [ 6.939349][ T58] Freeing initrd memory: 9448K [ 7.409866][ T1] Initialise system trusted keyrings [ 7.409945][ T1] Key type blacklist registered [ 7.410202][ T1] workingset: timestamp_bits=30 max_order=15 bucket_order=0 [ 7.410318][ T1] zbud: loaded [ 7.411703][ T1] NFS: Registering the id_resolver key type [ 7.411748][ T1] Key type id_resolver registered [ 7.411761][ T1] Key type id_legacy registered [ 7.411801][ T1] nfs4filelayout_init: NFSv4 File Layout Driver Registering... [ 7.411825][ T1] nfs4flexfilelayout_init: NFSv4 Flexfile Layout Driver Registering... [ 7.411838][ T1] Installing knfsd (copyright (C) 1996 okir@monad.swb.de). [ 7.412095][ T1] jffs2: version 2.2. (NAND) (SUMMARY) © 2001-2006 Red Hat, Inc. [ 7.412609][ T1] fuse: init (API version 7.34) [ 7.412985][ T1] orangefs_debugfs_init: called with debug mask: :none: :0: [ 7.413182][ T1] orangefs_init: module version upstream loaded [ 7.413200][ T1] SGI XFS with ACLs, security attributes, realtime, scrub, quota, no debug enabled [ 7.494892][ T1] xor: measuring software checksum speed [ 7.502001][ T1] arm4regs : 1391 MB/sec [ 7.513887][ T1] 8regs : 834 MB/sec [ 7.522002][ T1] 32regs : 1214 MB/sec [ 7.522014][ T1] xor: using function: arm4regs (1391 MB/sec) [ 7.522034][ T1] async_tx: api initialized (async) [ 7.522053][ T1] Key type asymmetric registered [ 7.522064][ T1] Asymmetric key parser 'x509' registered [ 7.522125][ T1] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 246) [ 7.522198][ T1] io scheduler bfq registered [ 7.682245][ T1] kirkwood-pinctrl f1010000.pin-controller: registered pinctrl driver [ 7.684312][ T1] mv_xor f1060800.xor: Marvell shared XOR driver [ 7.744386][ T1] mv_xor f1060800.xor: Marvell XOR (Registers Mode): ( xor cpy intr ) [ 7.746641][ T1] mv_xor f1060900.xor: Marvell shared XOR driver [ 7.804380][ T1] mv_xor f1060900.xor: Marvell XOR (Registers Mode): ( xor cpy intr ) [ 7.806859][ T1] Serial: 8250/16550 driver, 2 ports, IRQ sharing disabled [ 7.808128][ T1] printk: console [ttyS0] disabled [ 7.808220][ T1] f1012000.serial: ttyS0 at MMIO 0xf1012000 (irq = 25, base_baud = 12500000) is a 16550A [ 8.658028][ T1] printk: console [ttyS0] enabled [ 8.670880][ T1] loop: module loaded [ 8.675554][ T1] sata_mv f1080000.sata: slots 32 ports 2 [ 8.684731][ T1] scsi host0: sata_mv [ 8.689204][ T1] scsi host1: sata_mv [ 8.693298][ T1] ata1: SATA max UDMA/133 irq 32 [ 8.698179][ T1] ata2: SATA max UDMA/133 irq 32 [ 8.704055][ T1] nand: device found, Manufacturer ID: 0x2c, Chip ID: 0xda [ 8.711201][ T1] nand: Micron MT29F2G08AAD [ 8.715606][ T1] nand: 256 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 64 [ 8.724172][ T1] Scanning device for bad blocks [ 8.964307][ T1] 4 cmdlinepart partitions found on MTD device orion_nand [ 8.971330][ T1] Creating 4 MTD partitions on "orion_nand": [ 8.977240][ T1] 0x000000000000-0x000000100000 : "u-boot" [ 8.984395][ T1] 0x000000100000-0x000000500000 : "uImage" [ 8.991392][ T1] 0x000000500000-0x000002500000 : "rootfs" [ 8.998514][ T1] 0x000002500000-0x000010000000 : "data" [ 9.006603][ T1] wireguard: WireGuard 1.0.0 loaded. See www.wireguard.com for information. [ 9.015250][ T1] wireguard: Copyright (C) 2015-2019 Jason A. Donenfeld <Jason@zx2c4.com>. All Rights Reserved. [ 9.026671][ T1] libphy: Fixed MDIO Bus: probed [ 9.032888][ T1] libphy: orion_mdio_bus: probed [ 9.037776][ T94] ata1: SATA link down (SStatus 0 SControl F300) [ 9.059142][ T1] mv643xx_eth: MV-643xx 10/100/1000 ethernet driver version 1.4 [ 9.384981][ T96] ata2: SATA link down (SStatus 0 SControl F300) [ 9.824428][ T1] mv643xx_eth_port mv643xx_eth_port.0 eth0: port 0 with MAC address 00:10:75:1a:94:3f [ 9.834064][ T1] ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver [ 9.841357][ T1] ehci-pci: EHCI PCI platform driver [ 9.846602][ T1] ehci-orion: EHCI orion driver [ 9.851514][ T1] orion-ehci f1050000.ehci: EHCI Host Controller [ 9.857786][ T1] orion-ehci f1050000.ehci: new USB bus registered, assigned bus number 1 [ 9.866383][ T1] orion-ehci f1050000.ehci: irq 29, io mem 0xf1050000 [ 9.893480][ T1] orion-ehci f1050000.ehci: USB 2.0 started, EHCI 1.00 [ 9.900507][ T1] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 5.13 [ 9.909543][ T1] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1 [ 9.917522][ T1] usb usb1: Product: EHCI Host Controller [ 9.923121][ T1] usb usb1: Manufacturer: Linux 5.13.6-kirkwood-tld-1 ehci_hcd [ 9.930567][ T1] usb usb1: SerialNumber: f1050000.ehci [ 9.936644][ T1] hub 1-0:1.0: USB hub found [ 9.941157][ T1] hub 1-0:1.0: 1 port detected [ 9.946559][ T1] usbcore: registered new interface driver usb-storage [ 9.953726][ T1] mousedev: PS/2 mouse device common for all mice [ 10.233471][ T17] usb 1-1: new high-speed USB device number 2 using orion-ehci [ 10.435253][ T17] usb 1-1: New USB device found, idVendor=05e3, idProduct=0608, bcdDevice= 6.03 [ 10.444202][ T17] usb 1-1: New USB device strings: Mfr=0, Product=1, SerialNumber=0 [ 10.452093][ T17] usb 1-1: Product: USB2.0 Hub [ 10.457567][ T17] hub 1-1:1.0: USB hub found [ 10.462382][ T17] hub 1-1:1.0: 4 ports detected [ 10.783464][ T17] usb 1-1.2: new high-speed USB device number 3 using orion-ehci [ 10.934752][ T17] usb 1-1.2: New USB device found, idVendor=2537, idProduct=1068, bcdDevice= 1.00 [ 10.943873][ T17] usb 1-1.2: New USB device strings: Mfr=1, Product=2, SerialNumber=3 [ 10.951936][ T17] usb 1-1.2: Product: Device [ 10.956423][ T17] usb 1-1.2: Manufacturer: USB3.0 External [ 10.962196][ T17] usb 1-1.2: SerialNumber: 0123456789ABCDE [ 10.968674][ T17] usb-storage 1-1.2:1.0: USB Mass Storage device detected [ 10.976136][ T17] usb-storage 1-1.2:1.0: Quirks match for vid 2537 pid 1068: 800000 [ 10.984171][ T17] scsi host2: usb-storage 1-1.2:1.0 [ 11.043477][ T1] rtc-mv f1010300.rtc: internal RTC not ticking [ 11.049768][ T1] i2c /dev entries driver [ 11.054581][ T1] device-mapper: uevent: version 1.0.3 [ 11.060209][ T1] device-mapper: ioctl: 4.45.0-ioctl (2021-03-22) initialised: dm-devel@redhat.com [ 11.069831][ T1] device-mapper: multipath round-robin: version 1.2.0 loaded [ 11.077151][ T1] device-mapper: multipath queue-length: version 0.2.0 loaded [ 11.084530][ T1] device-mapper: multipath service-time: version 0.3.0 loaded [ 11.091935][ T1] device-mapper: dm-log-userspace: version 1.3.0 loaded [ 11.098782][ T1] device-mapper: raid: Loading target version 1.15.1 [ 11.107695][ T1] hid: raw HID events driver (C) Jiri Kosina [ 11.113923][ T1] drop_monitor: Initializing network drop monitor service [ 11.121359][ T1] NET: Registered protocol family 10 [ 11.127970][ T1] Segment Routing with IPv6 [ 11.132359][ T1] RPL Segment Routing with IPv6 [ 11.137248][ T1] NET: Registered protocol family 17 [ 11.142645][ T1] Key type dns_resolver registered [ 11.148174][ T1] registered taskstats version 1 [ 11.153004][ T1] Loading compiled-in X.509 certificates [ 11.159002][ T1] zswap: loaded using pool lzo/zbud [ 11.164477][ T1] Key type ._fscrypt registered [ 11.169209][ T1] Key type .fscrypt registered [ 11.173915][ T1] Key type fscrypt-provisioning registered [ 11.181788][ T1] Key type big_key registered [ 11.213709][ T1] Key type encrypted registered [ 11.224821][ T1] Freeing unused kernel memory: 1024K [ 11.244135][ T1] Checked W+X mappings: passed, no W+X pages found [ 11.250544][ T1] Run /init as init process Loading, please wait... Starting version 247.3-6 [ 12.159074][ T139] usbcore: registered new interface driver uas Begin: Loading essential drivers ... done. [ 13.527247][ T58] scsi 2:0:0:0: Direct-Access USB3.0 External Device LVM1 PQ: 0 ANSI: 6 [ 13.541444][ T7] sd 2:0:0:0: [sda] 976773168 512-byte logical blocks: (500 GB/466 GiB) [ 13.555553][ T7] sd 2:0:0:0: [sda] Write Protect is off [ 13.561783][ T7] sd 2:0:0:0: [sda] Write cache: disabled, read cache: enabled, doesn't support DPO or FUA [ 15.124787][ T7] sda: sda1 sda2 sda3 [ 15.136554][ T7] sd 2:0:0:0: [sda] Attached SCSI disk Begin: Running /scripts/init-premount ... done. Begin: Mounting root file system ... Begin: Running /scripts/local-top ... done. Begin: Running /scripts/local-premount ... done. Begin: Will now check root file system ... fsck from util-linux 2.36.1 [/sbin/fsck.ext3 (1) -- /dev/sda1] fsck.ext3 -a -C0 /dev/sda1 rootfs: clean, 15642/655360 files, 229886/2621184 blocks done. [ 23.096450][ T168] EXT4-fs (sda1): mounting ext3 file system using the ext4 subsystem [ 23.329283][ T168] EXT4-fs (sda1): mounted filesystem with ordered data mode. Opts: (null). Quota mode: none. done. Begin: Running /scripts/local-bottom ... done. Begin: Running /scripts/init-bottom ... done. INIT: version 2.96 booting Using makefile-style concurrent boot in runlevel S. Setting hostname to 'debian'...done. Starting hotplug events dispatcher: systemd-udevd. Synthesizing the initial hotplug events (subsystems)...done. Synthesizing the initial hotplug events (devices)...done. Waiting for /dev to be fully populated...[ 27.459249][ T359] orion_wdt: Initial timeout 21 sec [ 27.877000][ C0] random: crng init done [ 27.975840][ T352] sd 2:0:0:0: Attached scsi generic sg0 type 0 [ 27.991277][ T354] marvell-cesa f1030000.crypto: CESA device successfully registered done. Activating swap:. [ 30.465608][ T500] EXT4-fs (sda1): re-mounted. Opts: errors=remount-ro. Quota mode: none. Will now check all file systems. Checking all file systems. LABEL=rootfs is mounted Done checking file systems. Log is being saved in /var/log/fsck/checkfs if that location is writable. Cleaning up temporary files...Cleaning /tmp...done. /tmp. Will now mount local filesystems:. Will now activate swapfile swap, if any:done. Checking minimum space in /tmp...done. Cleaning up temporary files.... Initializing random number generator...done. Starting Setting kernel variables: sysctl . Configuring network interfaces...Internet Systems Consortium DHCP Client 4.4.1 Copyright 2004-2018 Internet Systems Consortium. All rights reserved. For info, please visit https://www.isc.org/software/dhcp/ Listening on LPF/eth0/00:10:75:1a:94:3f Sending on LPF/eth0/00:10:75:1a:94:3f Sending on Socket/fallback DHCPREQUEST for 192.168.0.15 on eth0 to 255.255.255.255 port 67 [ 36.702425][ C0] mv643xx_eth_port mv643xx_eth_port.0 eth0: link up, 1000 Mb/s, full duplex, flow control disabled [ 36.713075][ T17] IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready DHCPREQUEST for 192.168.0.15 on eth0 to 255.255.255.255 port 67 DHCPACK of 192.168.0.15 from 192.168.0.1 bound to 192.168.0.15 -- renewal in 32851 seconds. done. Starting RPC port mapper daemon: rpcbind. Starting NFS common utilities: statd idmapd. Cleaning up temporary files.... INIT: Entering runlevel: 2 Using makefile-style concurrent boot in runlevel 2. Starting busybox' syslogd implementation : syslogdStarting /sbin/syslogd... 1057 (syslogd) . Starting NFS common utilities: statd idmapd. Starting system message bus: dbus. Starting Avahi mDNS/DNS-SD Daemon: avahi-daemon. Not starting NFS kernel daemon: no exports. ... (warning). Starting NTP server: ntpd. Starting OpenBSD Secure Shell server: sshd. Starting busybox' klogd implementation : klogdStarting /sbin/klogd... 1091 (klogd) . Running local boot scripts (/etc/rc.local) . Debian GNU/Linux 11 debian ttyS0 debian login:
U-Boot 2017.07-tld-1 (Sep 05 2017 - 00:17:19 -0700) Seagate GoFlex Net SoC: Kirkwood 88F6281_A0 DRAM: 256 MiB WARNING: Caches not enabled NAND: 256 MiB In: serial Out: serial Err: serial Net: egiga0 88E1116 Initialized on egiga0 Hit any key to stop autoboot: 0 starting USB... USB0: USB EHCI 1.00 scanning bus 0 for devices... 3 USB Device(s) found scanning usb for storage devices... Use USB retry period from the environment: 15 second(s) 1 Storage Device(s) found Reset IDE: ide_preinit failed Partition Map for USB device 0 -- Partition Type: DOS Part Start Sector Num Sectors UUID Type 1 53817344 20969472 e9df59ed-01 83 Boot 2 74788864 1048576 e9df59ed-02 82 3 75837440 900933632 e9df59ed-03 83 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 ## Unknown partition table type 0 loading envs from usb 0 ... ** File not found /boot/uEnv.txt ** no IDE devices available running scan_disk ... Scan device usb device usb 0:1 1 bytes read in 723 ms (0 Bytes/s) Found bootable drive on usb 0 loading uImage ... 5435888 bytes read in 1004 ms (5.2 MiB/s) loading uInitrd ... 9671091 bytes read in 966 ms (9.5 MiB/s) loading DTB /boot/dts/kirkwood-goflexnet.dtb ... 11457 bytes read in 1769 ms (5.9 KiB/s) ## Booting kernel from Legacy Image at 00800000 ... Image Name: Linux-5.13.6-kirkwood-tld-1 Created: 2021-09-24 0:22:58 UTC Image Type: ARM Linux Kernel Image (uncompressed) Data Size: 5435824 Bytes = 5.2 MiB Load Address: 00008000 Entry Point: 00008000 Verifying Checksum ... OK ## Loading init Ramdisk from Legacy Image at 01100000 ... Image Name: initramfs-5.13.6-kirkwood-tld-1 Created: 2021-09-24 1:06:32 UTC Image Type: ARM Linux RAMDisk Image (gzip compressed) Data Size: 9671027 Bytes = 9.2 MiB Load Address: 00000000 Entry Point: 00000000 Verifying Checksum ... OK ## Flattened Device Tree blob at 01c00000 Booting using the fdt blob at 0x1c00000 Loading Kernel Image ... OK Loading Ramdisk to 0f1d4000, end 0fb0d173 ... OK Loading Device Tree to 0f1ce000, end 0f1d3cc0 ... OK Starting kernel ... Uncompressing Linux... done, booting the kernel. [ 0.000000][ T0] Booting Linux on physical CPU 0x0 [ 0.000000][ T0] Linux version 5.13.6-kirkwood-tld-1 (root@tldDebian) (gcc (Debian 8.3.0-6) 8.3.0, GNU ld (GNU Binutils for Debian) 2.31.1) #1.0 PREEMPT Sat Jul 31 22:10:39 PDT 2021 [ 0.000000][ T0] CPU: Feroceon 88FR131 [56251311] revision 1 (ARMv5TE), cr=0005397f [ 0.000000][ T0] CPU: VIVT data cache, VIVT instruction cache [ 0.000000][ T0] OF: fdt: Machine model: Seagate GoFlex Net [ 0.000000][ T0] Memory policy: Data cache writeback [ 0.000000][ T0] Zone ranges: [ 0.000000][ T0] Normal [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000][ T0] Movable zone start for each node [ 0.000000][ T0] Early memory node ranges [ 0.000000][ T0] node 0: [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000][ T0] Initmem setup node 0 [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000][ T0] Built 1 zonelists, mobility grouping on. Total pages: 65024 [ 0.000000][ T0] Kernel command line: console=ttyS0,115200 root=LABEL=rootfs rootdelay=10 mtdparts=orion_nand:1M(u-boot),4M(uImage),32M(rootfs),-(data) [ 0.000000][ T0] Dentry cache hash table entries: 32768 (order: 5, 131072 bytes, linear) [ 0.000000][ T0] Inode-cache hash table entries: 16384 (order: 4, 65536 bytes, linear) [ 0.000000][ T0] mem auto-init: stack:off, heap alloc:on, heap free:off [ 0.000000][ T0] Memory: 231056K/262144K available (11264K kernel code, 1553K rwdata, 4272K rodata, 1024K init, 309K bss, 31088K reserved, 0K cma-reserved) [ 0.000000][ T0] random: get_random_u32 called from ____cache_alloc+0x408/0x7b4 with crng_init=0 [ 0.000000][ T0] trace event string verifier disabled [ 0.000000][ T0] rcu: Preemptible hierarchical RCU implementation. [ 0.000000][ T0] Trampoline variant of Tasks RCU enabled. [ 0.000000][ T0] Tracing variant of Tasks RCU enabled. [ 0.000000][ T0] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies. [ 0.000000][ T0] NR_IRQS: 16, nr_irqs: 16, preallocated irqs: 16 [ 0.000000][ T0] clocksource: orion_clocksource: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 9556302233 ns [ 0.000002][ T0] sched_clock: 32 bits at 200MHz, resolution 5ns, wraps every 10737418237ns [ 0.000057][ T0] Switching to timer-based delay loop, resolution 5ns [ 0.000848][ T0] Console: colour dummy device 80x30 [ 0.000921][ T0] Calibrating delay loop (skipped), value calculated using timer frequency.. 400.00 BogoMIPS (lpj=2000000) [ 0.000962][ T0] pid_max: default: 32768 minimum: 301 [ 0.001336][ T0] LSM: Security Framework initializing [ 0.001510][ T0] Mount-cache hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 0.001557][ T0] Mountpoint-cache hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 0.002953][ T0] CPU: Testing write buffer coherency: ok [ 0.005436][ T1] Setting up static identity map for 0x100000 - 0x100058 [ 0.005729][ T1] mvebu-soc-id: MVEBU SoC ID=0x6281, Rev=0x2 [ 0.006084][ T1] rcu: Hierarchical SRCU implementation. [ 0.007485][ T1] devtmpfs: initialized [ 0.013337][ T1] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns [ 0.013392][ T1] futex hash table entries: 256 (order: -1, 3072 bytes, linear) [ 0.043464][ T1] prandom32: self test passed (less than 6 bits correlated) [ 0.043508][ T1] prandom: seed boundary self test passed [ 0.046879][ T1] prandom: 100 self tests passed [ 0.046897][ T1] pinctrl core: initialized pinctrl subsystem [ 0.048488][ T1] NET: Registered protocol family 16 [ 0.049355][ T1] DMA: preallocated 256 KiB pool for atomic coherent allocations [ 0.050369][ T1] audit: initializing netlink subsys (disabled) [ 0.051803][ T1] thermal_sys: Registered thermal governor 'step_wise' [ 0.052186][ T16] audit: type=2000 audit(0.050:1): state=initialized audit_enabled=0 res=1 [ 0.052352][ T1] cpuidle: using governor ladder [ 0.052451][ T1] cpuidle: using governor menu [ 0.052921][ T1] Feroceon L2: Enabling L2 [ 0.052972][ T1] Feroceon L2: Cache support initialised. [ 0.060736][ T1] No ATAGs? [ 2.560063][ C0] random: fast init done [ 3.970419][ T39] "cryptomgr_test" (39) uses obsolete ecb(arc4) skcipher [ 3.993329][ T59] wait_for_initramfs() called before rootfs_initcalls [ 4.180229][ T1] raid6: int32x8 gen() 134 MB/s [ 4.350196][ T1] raid6: int32x8 xor() 86 MB/s [ 4.520194][ T1] raid6: int32x4 gen() 136 MB/s [ 4.690148][ T1] raid6: int32x4 xor() 89 MB/s [ 4.860117][ T1] raid6: int32x2 gen() 176 MB/s [ 5.030164][ T1] raid6: int32x2 xor() 106 MB/s [ 5.200233][ T1] raid6: int32x1 gen() 121 MB/s [ 5.370078][ T1] raid6: int32x1 xor() 75 MB/s [ 5.370093][ T1] raid6: using algorithm int32x2 gen() 176 MB/s [ 5.370105][ T1] raid6: .... xor() 106 MB/s, rmw enabled [ 5.370115][ T1] raid6: using intx1 recovery algorithm [ 5.370373][ T1] vgaarb: loaded [ 5.370917][ T1] SCSI subsystem initialized [ 5.371405][ T1] usbcore: registered new interface driver usbfs [ 5.371481][ T1] usbcore: registered new interface driver hub [ 5.371534][ T1] usbcore: registered new device driver usb [ 5.371722][ T1] pps_core: LinuxPPS API ver. 1 registered [ 5.371736][ T1] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it> [ 5.371778][ T1] PTP clock support registered [ 5.373452][ T1] clocksource: Switched to clocksource orion_clocksource [ 5.464131][ T1] VFS: Disk quotas dquot_6.6.0 [ 5.464239][ T1] VFS: Dquot-cache hash table entries: 1024 (order 0, 4096 bytes) [ 5.476747][ T1] NET: Registered protocol family 2 [ 5.476931][ T1] IP idents hash table entries: 4096 (order: 3, 32768 bytes, linear) [ 5.483555][ T1] tcp_listen_portaddr_hash hash table entries: 512 (order: 0, 4096 bytes, linear) [ 5.483609][ T1] TCP established hash table entries: 2048 (order: 1, 8192 bytes, linear) [ 5.483658][ T1] TCP bind hash table entries: 2048 (order: 1, 8192 bytes, linear) [ 5.483697][ T1] TCP: Hash tables configured (established 2048 bind 2048) [ 5.483944][ T1] MPTCP token hash table entries: 512 (order: 0, 6144 bytes, linear) [ 5.484016][ T1] UDP hash table entries: 256 (order: 0, 4096 bytes, linear) [ 5.484054][ T1] UDP-Lite hash table entries: 256 (order: 0, 4096 bytes, linear) [ 5.484270][ T1] NET: Registered protocol family 1 [ 5.484983][ T1] RPC: Registered named UNIX socket transport module. [ 5.485004][ T1] RPC: Registered udp transport module. [ 5.485015][ T1] RPC: Registered tcp transport module. [ 5.485025][ T1] RPC: Registered tcp NFSv4.1 backchannel transport module. [ 5.485041][ T1] PCI: CLS 0 bytes, default 32 [ 5.485205][ T1] NetWinder Floating Point Emulator V0.97 (double precision) [ 5.485773][ T58] Trying to unpack rootfs image as initramfs... [ 6.949826][ T58] Freeing initrd memory: 9448K [ 7.414487][ T1] Initialise system trusted keyrings [ 7.414559][ T1] Key type blacklist registered [ 7.414819][ T1] workingset: timestamp_bits=30 max_order=16 bucket_order=0 [ 7.414939][ T1] zbud: loaded [ 7.416312][ T1] NFS: Registering the id_resolver key type [ 7.416355][ T1] Key type id_resolver registered [ 7.416368][ T1] Key type id_legacy registered [ 7.416409][ T1] nfs4filelayout_init: NFSv4 File Layout Driver Registering... [ 7.416432][ T1] nfs4flexfilelayout_init: NFSv4 Flexfile Layout Driver Registering... [ 7.416445][ T1] Installing knfsd (copyright (C) 1996 okir@monad.swb.de). [ 7.416703][ T1] jffs2: version 2.2. (NAND) (SUMMARY) © 2001-2006 Red Hat, Inc. [ 7.417215][ T1] fuse: init (API version 7.34) [ 7.417591][ T1] orangefs_debugfs_init: called with debug mask: :none: :0: [ 7.417791][ T1] orangefs_init: module version upstream loaded [ 7.417808][ T1] SGI XFS with ACLs, security attributes, realtime, scrub, quota, no debug enabled [ 7.499046][ T1] xor: measuring software checksum speed [ 7.506222][ T1] arm4regs : 1391 MB/sec [ 7.518082][ T1] 8regs : 834 MB/sec [ 7.526343][ T1] 32regs : 1201 MB/sec [ 7.526359][ T1] xor: using function: arm4regs (1391 MB/sec) [ 7.526380][ T1] async_tx: api initialized (async) [ 7.526399][ T1] Key type asymmetric registered [ 7.526410][ T1] Asymmetric key parser 'x509' registered [ 7.526469][ T1] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 246) [ 7.526546][ T1] io scheduler bfq registered [ 7.686506][ T1] kirkwood-pinctrl f1010000.pin-controller: registered pinctrl driver [ 7.688514][ T1] mv_xor f1060800.xor: Marvell shared XOR driver [ 7.744390][ T1] mv_xor f1060800.xor: Marvell XOR (Registers Mode): ( xor cpy intr ) [ 7.746639][ T1] mv_xor f1060900.xor: Marvell shared XOR driver [ 7.804369][ T1] mv_xor f1060900.xor: Marvell XOR (Registers Mode): ( xor cpy intr ) [ 7.806830][ T1] Serial: 8250/16550 driver, 2 ports, IRQ sharing disabled [ 7.808098][ T1] printk: console [ttyS0] disabled [ 7.808188][ T1] f1012000.serial: ttyS0 at MMIO 0xf1012000 (irq = 25, base_baud = 12500000) is a 16550A [ 8.658162][ T1] printk: console [ttyS0] enabled [ 8.670944][ T1] loop: module loaded [ 8.675619][ T1] sata_mv f1080000.sata: slots 32 ports 2 [ 8.684792][ T1] scsi host0: sata_mv [ 8.689267][ T1] scsi host1: sata_mv [ 8.693359][ T1] ata1: SATA max UDMA/133 irq 32 [ 8.698241][ T1] ata2: SATA max UDMA/133 irq 32 [ 8.704115][ T1] nand: device found, Manufacturer ID: 0x2c, Chip ID: 0xda [ 8.711257][ T1] nand: Micron MT29F2G08AAD [ 8.715662][ T1] nand: 256 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 64 [ 8.724226][ T1] Scanning device for bad blocks [ 8.964373][ T1] 4 cmdlinepart partitions found on MTD device orion_nand [ 8.971404][ T1] Creating 4 MTD partitions on "orion_nand": [ 8.977311][ T1] 0x000000000000-0x000000100000 : "u-boot" [ 8.984471][ T1] 0x000000100000-0x000000500000 : "uImage" [ 8.991452][ T1] 0x000000500000-0x000002500000 : "rootfs" [ 8.998556][ T1] 0x000002500000-0x000010000000 : "data" [ 9.006616][ T1] wireguard: WireGuard 1.0.0 loaded. See www.wireguard.com for information. [ 9.015268][ T1] wireguard: Copyright (C) 2015-2019 Jason A. Donenfeld <Jason@zx2c4.com>. All Rights Reserved. [ 9.026700][ T1] libphy: Fixed MDIO Bus: probed [ 9.032891][ T1] libphy: orion_mdio_bus: probed [ 9.037780][ T94] ata1: SATA link down (SStatus 0 SControl F300) [ 9.059328][ T1] mv643xx_eth: MV-643xx 10/100/1000 ethernet driver version 1.4 [ 9.384990][ T96] ata2: SATA link down (SStatus 0 SControl F300) [ 9.824429][ T1] mv643xx_eth_port mv643xx_eth_port.0 eth0: port 0 with MAC address 00:10:75:1a:94:3f [ 9.834065][ T1] ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver [ 9.841350][ T1] ehci-pci: EHCI PCI platform driver [ 9.846594][ T1] ehci-orion: EHCI orion driver [ 9.851507][ T1] orion-ehci f1050000.ehci: EHCI Host Controller [ 9.857777][ T1] orion-ehci f1050000.ehci: new USB bus registered, assigned bus number 1 [ 9.866375][ T1] orion-ehci f1050000.ehci: irq 29, io mem 0xf1050000 [ 9.893488][ T1] orion-ehci f1050000.ehci: USB 2.0 started, EHCI 1.00 [ 9.900508][ T1] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 5.13 [ 9.909545][ T1] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1 [ 9.917525][ T1] usb usb1: Product: EHCI Host Controller [ 9.923124][ T1] usb usb1: Manufacturer: Linux 5.13.6-kirkwood-tld-1 ehci_hcd [ 9.930570][ T1] usb usb1: SerialNumber: f1050000.ehci [ 9.936654][ T1] hub 1-0:1.0: USB hub found [ 9.941168][ T1] hub 1-0:1.0: 1 port detected [ 9.946567][ T1] usbcore: registered new interface driver usb-storage [ 9.953730][ T1] mousedev: PS/2 mouse device common for all mice [ 10.233481][ T17] usb 1-1: new high-speed USB device number 2 using orion-ehci [ 10.435242][ T17] usb 1-1: New USB device found, idVendor=05e3, idProduct=0608, bcdDevice= 6.03 [ 10.444196][ T17] usb 1-1: New USB device strings: Mfr=0, Product=1, SerialNumber=0 [ 10.452082][ T17] usb 1-1: Product: USB2.0 Hub [ 10.457557][ T17] hub 1-1:1.0: USB hub found [ 10.462372][ T17] hub 1-1:1.0: 4 ports detected [ 10.783472][ T17] usb 1-1.2: new high-speed USB device number 3 using orion-ehci [ 10.934741][ T17] usb 1-1.2: New USB device found, idVendor=2537, idProduct=1068, bcdDevice= 1.00 [ 10.943860][ T17] usb 1-1.2: New USB device strings: Mfr=1, Product=2, SerialNumber=3 [ 10.951931][ T17] usb 1-1.2: Product: Device [ 10.956418][ T17] usb 1-1.2: Manufacturer: USB3.0 External [ 10.962191][ T17] usb 1-1.2: SerialNumber: 0123456789ABCDE [ 10.968665][ T17] usb-storage 1-1.2:1.0: USB Mass Storage device detected [ 10.976129][ T17] usb-storage 1-1.2:1.0: Quirks match for vid 2537 pid 1068: 800000 [ 10.984177][ T17] scsi host2: usb-storage 1-1.2:1.0 [ 11.043485][ T1] rtc-mv f1010300.rtc: internal RTC not ticking [ 11.049778][ T1] i2c /dev entries driver [ 11.054589][ T1] device-mapper: uevent: version 1.0.3 [ 11.060209][ T1] device-mapper: ioctl: 4.45.0-ioctl (2021-03-22) initialised: dm-devel@redhat.com [ 11.069844][ T1] device-mapper: multipath round-robin: version 1.2.0 loaded [ 11.077164][ T1] device-mapper: multipath queue-length: version 0.2.0 loaded [ 11.084541][ T1] device-mapper: multipath service-time: version 0.3.0 loaded [ 11.091944][ T1] device-mapper: dm-log-userspace: version 1.3.0 loaded [ 11.098785][ T1] device-mapper: raid: Loading target version 1.15.1 [ 11.107702][ T1] hid: raw HID events driver (C) Jiri Kosina [ 11.113930][ T1] drop_monitor: Initializing network drop monitor service [ 11.121363][ T1] NET: Registered protocol family 10 [ 11.127948][ T1] Segment Routing with IPv6 [ 11.132335][ T1] RPL Segment Routing with IPv6 [ 11.137223][ T1] NET: Registered protocol family 17 [ 11.142605][ T1] Key type dns_resolver registered [ 11.148130][ T1] registered taskstats version 1 [ 11.152955][ T1] Loading compiled-in X.509 certificates [ 11.158951][ T1] zswap: loaded using pool lzo/zbud [ 11.164429][ T1] Key type ._fscrypt registered [ 11.169160][ T1] Key type .fscrypt registered [ 11.173869][ T1] Key type fscrypt-provisioning registered [ 11.181730][ T1] Key type big_key registered [ 11.213712][ T1] Key type encrypted registered [ 11.224763][ T1] Freeing unused kernel memory: 1024K [ 11.244163][ T1] Checked W+X mappings: passed, no W+X pages found [ 11.250564][ T1] Run /init as init process Loading, please wait... Starting version 247.3-6 [ 12.165928][ T142] usbcore: registered new interface driver uas Begin: Loading essential drivers ... done. [ 13.527109][ T58] scsi 2:0:0:0: Direct-Access USB3.0 External Device LVM1 PQ: 0 ANSI: 6 [ 13.541431][ T7] sd 2:0:0:0: [sda] 976773168 512-byte logical blocks: (500 GB/466 GiB) [ 13.555415][ T7] sd 2:0:0:0: [sda] Write Protect is off [ 13.561647][ T7] sd 2:0:0:0: [sda] Write cache: disabled, read cache: enabled, doesn't support DPO or FUA [ 15.130774][ T7] sda: sda1 sda2 sda3 [ 15.146543][ T7] sd 2:0:0:0: [sda] Attached SCSI disk Begin: Running /scripts/init-premount ... done. Begin: Mounting root file system ... Begin: Running /scripts/local-top ... done. Begin: Running /scripts/local-premount ... done. Begin: Will now check root file system ... fsck from util-linux 2.36.1 [/sbin/fsck.ext3 (1) -- /dev/sda1] fsck.ext3 -a -C0 /dev/sda1 rootfs: clean, 15643/655360 files, 229889/2621184 blocks done. [ 23.068814][ T168] EXT4-fs (sda1): mounting ext3 file system using the ext4 subsystem [ 23.301900][ T168] EXT4-fs (sda1): mounted filesystem with ordered data mode. Opts: (null). Quota mode: none. done. Begin: Running /scripts/local-bottom ... done. Begin: Running /scripts/init-bottom ... done. INIT: version 2.96 booting Using makefile-style concurrent boot in runlevel S. Setting hostname to 'debian'...done. Starting hotplug events dispatcher: systemd-udevd. Synthesizing the initial hotplug events (subsystems)...done. Synthesizing the initial hotplug events (devices)...done. Waiting for /dev to be fully populated...[ 27.510137][ T352] orion_wdt: Initial timeout 21 sec [ 27.840387][ C0] random: crng init done [ 27.890505][ T354] sd 2:0:0:0: Attached scsi generic sg0 type 0 [ 27.964111][ T357] marvell-cesa f1030000.crypto: CESA device successfully registered done. Activating swap:. [ 30.549217][ T500] EXT4-fs (sda1): re-mounted. Opts: errors=remount-ro. Quota mode: none. Will now check all file systems. Checking all file systems. LABEL=rootfs is mounted Done checking file systems. Log is being saved in /var/log/fsck/checkfs if that location is writable. Cleaning up temporary files...Cleaning /tmp...done. /tmp. Will now mount local filesystems:. Will now activate swapfile swap, if any:done. Checking minimum space in /tmp...done. Cleaning up temporary files.... Starting Setting kernel variables: sysctl. Initializing random number generator...done. Configuring network interfaces...Internet Systems Consortium DHCP Client 4.4.1 Copyright 2004-2018 Internet Systems Consortium. All rights reserved. For info, please visit https://www.isc.org/software/dhcp/ Listening on LPF/eth0/00:10:75:1a:94:3f Sending on LPF/eth0/00:10:75:1a:94:3f Sending on Socket/fallback DHCPREQUEST for 192.168.0.15 on eth0 to 255.255.255.255 port 67 [ 36.708833][ C0] mv643xx_eth_port mv643xx_eth_port.0 eth0: link up, 1000 Mb/s, full duplex, flow control disabled [ 36.719495][ T17] IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready DHCPREQUEST for 192.168.0.15 on eth0 to 255.255.255.255 port 67 DHCPACK of 192.168.0.15 from 192.168.0.1 bound to 192.168.0.15 -- renewal in 32851 seconds. done. Starting RPC port mapper daemon: rpcbind. Starting NFS common utilities: statd idmapd. Cleaning up temporary files.... INIT: Entering runlevel: 2 Using makefile-style concurrent boot in runlevel 2. Starting busybox' syslogd implementation : syslogdStarting /sbin/syslogd... 1054 (syslogd) . Starting NFS common utilities: statd idmapd. Starting system message bus: dbus. Starting Avahi mDNS/DNS-SD Daemon: avahi-daemon. Not starting NFS kernel daemon: no exports. ... (warning). Starting NTP server: ntpd. Starting OpenBSD Secure Shell server: sshd. Starting busybox' klogd implementation : klogdStarting /sbin/klogd... 1092 (klogd) . Running local boot scripts (/etc/rc.local) . Debian GNU/Linux 11 debian ttyS0 debian login:
Re: Dockstar HW mod: Trying to add native sata November 18, 2021 09:21PM |
Admin Registered: 13 years ago Posts: 18,821 |
Re: Dockstar HW mod: Trying to add native sata November 19, 2021 10:20AM |
Registered: 2 years ago Posts: 56 |
Re: Dockstar HW mod: Trying to add native sata November 19, 2021 03:07PM |
Admin Registered: 13 years ago Posts: 18,821 |
Re: Dockstar HW mod: Trying to add native sata November 19, 2021 05:19PM |
Registered: 2 years ago Posts: 56 |
Re: Dockstar HW mod: Trying to add native sata November 19, 2021 07:29PM |
Admin Registered: 13 years ago Posts: 18,821 |
Re: Dockstar HW mod: Trying to add native sata November 20, 2021 05:15PM |
Registered: 2 years ago Posts: 56 |
BOOT0 = 1 RX PA9 TX PA10If using internal bootloader method, restore BOOT0 to position 0 after programming.
TCK: B13 TDO: B14 TDI: B15 TMS: B4 nTRST: B10
interface vsllink adapter_khz 250 transport select jtag
# For Seagate Dockstar and other 128MB kirkwood devices # Based on Alexander's guide: # https://lunarius.fe80.eu/blog/openwrt-dockstar-jtag.html # # Modified DDR SRAM settings for 128MB single chip kirkwood devices # Original code for sheevaplug is not correct, DRAM config is different source [find vsllink.cfg] source [find target/feroceon.cfg] $_TARGETNAME configure \ -work-area-phys 0x100000 \ -work-area-size 16777216 \ -work-area-backup 0 # Slightly faster transfer speed arm7_9 dcc_downloads enable # This assumes the hardware default peripherals location before u-Boot moves it set _FLASHNAME $_CHIPNAME.flash nand device $_FLASHNAME orion feroceon.cpu 0xd8000000 proc _init { } { # We need to assert DBGRQ while holding nSRST down. # However DBGACK will be set only when nSRST is released. # Furthermore, the JTAG interface doesn't respond at all when # the CPU is in the WFI (wait for interrupts) state, so it is # possible that initial tap examination failed. So let's # re-examine the target again here when nSRST is asserted which # should then succeed. jtag_reset 0 1 feroceon.cpu arp_examine halt 0 jtag_reset 0 0 wait_halt arm mcr 15 0 0 1 0 0x00052078 mww 0xD0001400 0x43000c30 ;# DDR SDRAM Configuration Register mww 0xD0001404 0x37543000 ;# DDR SDRAM Control Low mww 0xD0001408 0x22125451 ;# DDR SDRAM Timing (Low) Register mww 0xD000140C 0x00000a33 ;# DDR SDRAM Timing (High) Register mww 0xD0001410 0x0000000d ;# DDR SDRAM Address Control Register (1Gbit, x16) mww 0xD0001414 0x00000000 ;# DDR SDRAM Open Pages Control Register mww 0xD0001418 0x00000000 ;# DDR SDRAM Operation Register mww 0xD000141C 0x00000C52 ;# DDR SDRAM Mode Register mww 0xD0001420 0x00000040 ;# DDR SDRAM Extended Mode Register mww 0xD0001424 0x0000F17F ;# DDR SDRAM Control High mww 0xD0001428 0x00085520 ;# DDR SDRAM ODT Read Timing (default values) mww 0xD000147c 0x00008552 ;# DDR SDRAM ODT Write Timing (default values) mww 0xD0001500 0x00000000 ;# DDR SDRAM CS[0]n Base address to 0x0 mww 0xD0001504 0x07FFFFF1 ;# DDR SDRAM CS[0]n Size Register (128MB) mww 0xD0001508 0x10000000 ;# DDR SDRAM CS[1]n Base address to 0x10000000 mww 0xD000150C 0x00000000 ;# DDR SDRAM CS[1]n Size Register, window disabled mww 0xD0001514 0x00000000 ;# DDR SDRAM CS[2]n Size Register, window disabled mww 0xD000151C 0x00000000 ;# DDR SDRAM CS[3]n Size Register, window disabled mww 0xD0001494 0x00030000 ;# DDR SDRAM ODT Control (Low) Register mww 0xD0001498 0x00000000 ;# DDR SDRAM ODT Control (High) REgister mww 0xD000149C 0x0000E803 ;# DDR SDRAM CPU ODT Control mww 0xD0001480 0x00000001 ;# DDR SDRAM Initialization Control Register mww 0xD0020204 0x00000000 ;# Main IRQ Interrupt Mask Register mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0020204 0x00000000 ;# " mww 0xD0010000 0x01111111 ;# MPP 0 to 7 mww 0xD0010004 0x11113322 ;# MPP 8 to 15 mww 0xD0010008 0x00001111 ;# MPP 16 to 23 mww 0xD0010418 0x003E07CF ;# NAND Read Parameters REgister mww 0xD001041C 0x000F0F0F ;# NAND Write Parameters Register mww 0xD0010470 0x01C7D943 ;# NAND Flash Control Register soft_reset_halt } proc flash_all { } { # Flash everything (uboot+env) nand probe 0 nand erase 0 0x0 0xa0000 nand write 0 uboot.kwb 0 oob_softecc nand erase 0 0xc0000 0x20000 nand write 0 uboot-env.bin 0xc0000 oob_softecc } proc flash_uboot { } { # Flash the u-Boot binary nand probe 0 nand erase 0 0x0 0xa0000 nand write 0 uboot.kwb 0 oob_softecc } proc flash_env { } { # Flash the u-Boot environment variables area nand probe 0 nand erase 0 0xc0000 0x20000 nand write 0 uboot-env.bin 0xc0000 oob_softecc } proc load_uboot { } { # Load u-Boot image into RAM and execute it load_image uboot.kwb verify_image uboot.kwb resume 0x800200 }
uboot.2017.07-tld-1.(board).mtd0.kwb -> Rename to uboot.kwb uboot.2016.05-tld-1.environment.img -> Rename to uboot-env.bin
openocd.exe -f docsktar.cfg
Open On-Chip Debugger 0.10.0 Licensed under GNU GPL v2 For bug reports, read http://openocd.org/doc/doxygen/bugs.html adapter speed: 250 kHz trst_and_srst separate srst_gates_jtag trst_push_pull srst_open_drain connect_deassert_srst adapter_nsrst_delay: 200 jtag_ntrst_delay: 200 dcc downloads are enabled load_uboot Info : Versaloon(0x15)by Simon(compiled on Dec 21 2018) Info : USB_TO_XXX abilities: 0x00000208:0x010001E3:0xC0000007 Info : clock speed 250 kHz Error: JTAG scan chain interrogation failed: all zeroes Error: Check JTAG interface, timings, target power, etc. Error: Trying to use configured scan chain anyway... Warn : Bypassing JTAG setup events due to errors Info : Embedded ICE version 0 Info : feroceon.cpu: hardware has 1 breakpoint/watchpoint unit Info : accepting 'telnet' connection on tcp/4444 target halted in Thumb state due to debug-request, current mode: Supervisor cpsr: 0x200000f3 pc: 0xffff0a8e MMU: enabled, D-Cache: enabled, I-Cache: enabled
Open On-Chip Debugger >
_init Init the CPU (Run this after opening openocd, before any other command) flash_all Flash u-boot and environment flash_uboot Flash u-boot only flash_env Flash environment only load_uboot Download uboot to ram and execute it (I have not tested it)
>_init target halted in ARM state due to debug-request, current mode: Supervisor cpsr: 0x800000d3 pc: 0x07f81d9c MMU: disabled, D-Cache: disabled, I-Cache: disabled requesting target halt and executing a soft reset target halted in ARM state due to debug-request, current mode: Supervisor cpsr: 0x800000d3 pc: 0x00000000 MMU: disabled, D-Cache: disabled, I-Cache: disabled >nand probe 0 NAND flash device 'NAND 256MiB 3.3V 8-bit (Micron)' found
> flash_all NAND flash device 'NAND 256MiB 3.3V 8-bit (Micron)' found erased blocks 0 to 4 on NAND flash device #0 'NAND 256MiB 3.3V 8-bit' wrote file uboot.kwb to NAND flash 0 up to offset 0x00080000 in 332.655731s (1.539 KiB/s) erased blocks 6 to 6 on NAND flash device #0 'NAND 256MiB 3.3V 8-bit' wrote file uboot-env.bin to NAND flash 0 up to offset 0x000e0000 in 82.984138s (1.542 KiB/s)
NAND read from offset c0000 failed -74 *** Warning - readenv() failed, using default environmentIt means the ECC is wrong, likely the selected nand ecc algorithm was incorrect.
GoFlexNet> nand read 0x100000 0 0x10Good ECC:
NAND read: device 0 offset 0x0, size 0x10 16 bytes read: OK
NAND read: device 0 offset 0x0, size 0x10 NAND read from offset 0 failed -74 0 bytes read: ERROR
nand write 0 ... oob_softeccto
nand write 0 ... oob_softecc_kwThen try again.
Re: Dockstar HW mod: Trying to add native sata November 21, 2021 01:50AM |
Registered: 2 years ago Posts: 56 |
#!/bin/sh ### BEGIN INIT INFO # Provides: button_monitor # Required-Start: # Required-Stop: # Should-Start: # Default-Start: 1 2 3 4 5 # Default-Stop: # Short-Description: Starts shutdown button daemon # Description: ### END INIT INFO PATH=/usr/sbin:/usr/bin:/sbin:/bin case "$1" in start) /usr/bin/button_monitor & ;; stop) ;; restart|reload) ;; *) echo "Usage: $0 {start|stop|restart}" exit 1 esac :
# Pressing time to trigger shutdown TIME=5 # Button gpio IO_BTN=36 # LED gpio IO_LED=49 # Time counter COUNT=0 echo "$IO_BTN" >/sys/class/gpio/export echo "in" > /sys/class/gpio/gpio$IO_BTN/direction echo "$IO_LED" >/sys/class/gpio/export echo "out" > /sys/class/gpio/gpio$IO_LED/direction echo "0" >/sys/class/gpio/gpio$IO_LED/value while true; do VAL="$(cat /sys/class/gpio/gpio$IO_BTN/value)" if [ $VAL -eq 0 ]; then COUNT=$(($COUNT+1)) if [ $COUNT -gt $TIME ]; then echo "Power button detected! Shutting down system" echo "1" >/sys/class/gpio/gpio$IO_LED/value poweroff & exit 0 fi else COUNT=0 fi sleep 1 done
chmod +x /usr/init.d/button_monitor /usr/bin/button_monitor update-rc.d -f button_monitor defaults
gpio [number] [mode] number: 45 for gpio45 mode: in or out Examples: gpio 45 out gpio 34 in Input mode: Shows the pin value in real time (1 or 0) Output mode: Toogles the output every second
GPIO=$1 if [ -z "$1" ]; then echo "No gpio provided" exit 1 elif [ -z "${1##*[!0-9]*}" ];then echo "Gpio must be a number!" exit 1 fi if [ -z "$2" ]; then echo "No mode provided" exit 1 elif [ "$2" != "in" ] && [ "$2" != "out" ]; then echo "Bad mode. Select \"in\" or \"out\"" exit 1 fi echo "$1" >/sys/class/gpio/export if [ $? -ne 0 ]; then echo "Error exporting gpio number" echo "$GPIO" >/sys/class/gpio/unexport exit 1 fi echo "$2" > /sys/class/gpio/gpio$1/direction if [ $? -ne 0 ]; then echo "Error setting gpio direction" echo "$GPIO" >/sys/class/gpio/unexport exit 1 fi function read_key { read -rsn1 -t0.001 KEY if [ "$KEY" == "q" ];then echo "$GPIO" >/sys/class/gpio/unexport exit 0 fi } echo Testing gpio $1 as $2 if [ "$2" == "in" ]; then while true; do cat /sys/class/gpio/gpio$1/value | tr '\n' '\r' sleep 0.1 read_key done else while true; do echo 1 >/sys/class/gpio/gpio$1/value sleep 1 read_key echo 0 >/sys/class/gpio/gpio$1/value sleep 1 read_key done fi
Re: Dockstar HW mod: Trying to add native sata November 21, 2021 02:58PM |
Admin Registered: 13 years ago Posts: 18,821 |
Quote
https://forum.doozan.com/read.php?2,23630
Key daemon (button control)
Multimedia keyboard daemon for Linux
How to use set up button to reboot or shutdown with Key Daemon (esekeyd)
Re: Dockstar HW mod: Trying to add native sata November 24, 2021 03:25AM |
Registered: 2 years ago Posts: 56 |
Re: Dockstar HW mod: Trying to add native sata November 24, 2021 03:35PM |
Admin Registered: 13 years ago Posts: 18,821 |
Re: Dockstar HW mod: Trying to add native sata November 25, 2021 08:15PM |
Registered: 2 years ago Posts: 56 |
wget https://releases.linaro.org/components/toolchain/binaries/latest-6/arm-linux-gnueabi/gcc-linaro-6.5.0-2018.12-x86_64_arm-linux-gnueabi.tar.xz sudo tar xvf gcc-linaro-6.5.0-2018.12-x86_64_arm-linux-gnueabi.tar.xz -C /usr/local/
export CROSS_COMPILE=/usr/local/gcc-linaro-6.5.0-2018.12-x86_64_arm-linux-gnueabi/bin/arm-linux-gnueabi- \ PATH=/usr/local/gcc-linaro-6.5.0-2018.12-x86_64_arm-linux-gnueabi/bin:$PATH
make clean; make goflexnet_defconfig; make -sj12 u-boot.kwb
CLEAN examples/standalone CLEAN tools CLEAN tools/lib tools/common CLEAN u-boot-nodtb.bin u-boot.lds u-boot.kwb u-boot.map u-boot.bin u-boot.cfg u-boot HOSTCC scripts/basic/fixdep HOSTCC scripts/kconfig/conf.o HOSTCC scripts/kconfig/zconf.tab.o In file included from scripts/kconfig/zconf.tab.c:2468: scripts/kconfig/confdata.c: In function ‘conf_write’: scripts/kconfig/confdata.c:771:19: warning: ‘%s’ directive writing likely 7 or more bytes into a region of size between 1 and 4097 [-Wformat-overflow=] 771 | sprintf(newname, "%s%s", dirname, basename); | ^~~~~~ scripts/kconfig/confdata.c:771:19: note: assuming directive output of 7 bytes In file included from /usr/include/stdio.h:867, from scripts/kconfig/zconf.tab.c:82: /usr/include/x86_64-linux-gnu/bits/stdio2.h:36:10: note: ‘__builtin___sprintf_chk’ output 1 or more bytes (assuming 4104) into a destination of size 4097 36 | return __builtin___sprintf_chk (__s, __USE_FORTIFY_LEVEL - 1, | ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ 37 | __bos (__s), __fmt, __va_arg_pack ()); | ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ In file included from scripts/kconfig/zconf.tab.c:2468: scripts/kconfig/confdata.c:774:20: warning: ‘.tmpconfig.’ directive writing 11 bytes into a region of size between 1 and 4097 [-Wformat-overflow=] 774 | sprintf(tmpname, "%s.tmpconfig.%d", dirname, (int)getpid()); | ^~~~~~~~~~~~~~~~~ In file included from /usr/include/stdio.h:867, from scripts/kconfig/zconf.tab.c:82: /usr/include/x86_64-linux-gnu/bits/stdio2.h:36:10: note: ‘__builtin___sprintf_chk’ output between 13 and 4119 bytes into a destination of size 4097 36 | return __builtin___sprintf_chk (__s, __USE_FORTIFY_LEVEL - 1, | ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ 37 | __bos (__s), __fmt, __va_arg_pack ()); | ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ HOSTLD scripts/kconfig/conf # # configuration written to .config #
flash_erase /dev/mtd0 0 4 nandwrite /dev/mtd0 -p u-boot.kwb
nanddump /dev/mtd0 -f read.kwb -l $(stat --printf="%s" u-boot.kwb) diff u-boot.kwb read.kwb
Binary files u-boot.kwb and read.kwb differ
Re: Dockstar HW mod: Trying to add native sata November 25, 2021 08:53PM |
Registered: 2 years ago Posts: 56 |
config TARGET_DOCKSTAR_MOD bool "Dockstar_mod Board" source "board/Seagate/dockstar_mod/Kconfig"
if TARGET_DOCKSTAR_MOD config SYS_BOARD default "dockstar_mod" config SYS_VENDOR default "Seagate" config SYS_CONFIG_NAME default "dockstar_mod" endif
#ifndef _CONFIG_DOCKSTAR_MOD_H #define _CONFIG_DOCKSTAR_MOD_H
CONFIG_TARGET_DOCKSTAR_MOD=y
make clean; make dockstar_mod_defconfig; make -sj12 u-boot.kwb
CONFIG_HUSH_PARSER=y CONFIG_CMD_IDE=y CONFIG_CMD_MMC=y
/* * SATA */ #ifdef CONFIG_MVSATA_IDE #define CONFIG_SYS_ATA_IDE0_OFFSET MV_SATA_PORT0_OFFSET #define CONFIG_SYS_ATA_IDE1_OFFSET MV_SATA_PORT1_OFFSET #endif /* * Kirkwood GPIO */ #define CONFIG_KIRKWOOD_GPIO /* * SDIO/MMC Card Configuration */ #ifdef CONFIG_CMD_MMC #define CONFIG_MVEBU_MMC #define CONFIG_SYS_MMC_BASE KW_SDIO_BASE #endif /* CONFIG_CMD_MMC */
U-Boot 2017.07-g697f50bf18-dirty (Nov 26 2021 - 05:19:58 +0100) Seagate FreeAgent DockStar SoC: Kirkwood 88F6281_A0 DRAM: 128 MiB WARNING: Caches not enabled NAND: 256 MiB MMC: MVEBU_MMC: 0 In: serial Out: serial Err: serial Net: egiga0 88E1116 Initialized on egiga0 Hit any key to stop autoboot: 0 DockStar> ide reset Reset IDE: Bus 0: OK Bus 1: not available Device 0: Model: WDC WD10JPVX-22JC3T0 Firm: 01.01A01 Ser#: WD-WX61E14X1081 Type: Hard Disk Supports 48-bit addressing Capacity: 953869.7 MB = 931.5 GB (1953525168 x 512) DockStar> mmc rescan MMC rescan: current device # 0 initialized OK DockStar> mmc info Device: MVEBU_MMC Manufacturer ID: 1b OEM: 534d Name: USD Tran Speed: 50000000 Rd Block Len: 512 SD version 2.0 High Capacity: No Capacity: 1.9 GiB Bus Width: 4-bit Erase Group Size: 512 Bytes DockStar>
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... November 26, 2021 07:28PM |
Registered: 2 years ago Posts: 56 |
export ARCH=arm CROSS_COMPILE=/usr/local/gcc-linaro-6.5.0-2018.12-x86_64_arm-linux-gnueabi/bin/arm-linux-gnueabi- PATH=/usr/local/gcc-linaro-6.5.0-2018.12-x86_64_arm-linux-gnueabi/bin:$PATH make clean make dockstar_defconfig make -sj12 dtbsThe dtb file is placed in /arch/arm/dts, same filename but with dtb extension (kirkwod-dockstar.dtb).
evtest /dev/input/event0 Input driver version is 1.0.1 Input device ID: bus 0x19 vendor 0x1 product 0x1 version 0x100 Input device name: "gpio_keys" Supported events: Event type 0 (EV_SYN) Event type 1 (EV_KEY) Event code 116 (KEY_POWER) Properties: Testing ... (interrupt to exit) Event: time 1637976351.226717, type 1 (EV_KEY), code 116 (KEY_POWER), value 1 Event: time 1637976351.226717, -------------- SYN_REPORT ------------ Event: time 1637976351.532663, type 1 (EV_KEY), code 116 (KEY_POWER), value 0 Event: time 1637976351.532663, -------------- SYN_REPORT ------------
echo 1 > /sys/class/leds/status\:red\:power/brightness echo 0 > /sys/class/leds/status\:red\:power/brightness
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... November 27, 2021 07:46PM |
Registered: 2 years ago Posts: 56 |
main_hdr->srcaddr = cpu_to_le32(headersz);Modify this code from this:
e = image_find_option(IMAGE_CFG_BOOT_FROM); if (e) main_hdr->blockid = e->bootfrom;To this:
e = image_find_option(IMAGE_CFG_BOOT_FROM); if (e){ main_hdr->blockid = e->bootfrom; if(main_hdr->blockid==0x78) // Boot from sata. HDD sector=512bytes // Get image from disk sector 2 (Sector 0 is MBR, sector 1 is kwb header) main_hdr->srcaddr = cpu_to_le32(headersz / 512 + 1); else // Nand or spi, header offset in bytes main_hdr->srcaddr = cpu_to_le32(headersz); }
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... November 28, 2021 05:35PM |
Admin Registered: 13 years ago Posts: 18,821 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... November 29, 2021 12:22AM |
Registered: 2 years ago Posts: 56 |
CONFIG_LEGACY_IMAGE_FORMAT=y CONFIG_SUPPORT_RAW_INITRD=y
CONFIG_CMD_FS_GENERIC=y
load_initrd=load $bootdev $device $load_initrd_addr /boot/uInitrd; setenv initrd_size $filesize boot_exec=bootm $load_uimage_addr $load_initrd_addr:$initrd_size $load_dtb_addr
U-Boot 2022.01-rc1-67610-g5c61710c98-dirty (Nov 29 2021 - 07:10:52 +0100) Seagate FreeAgent DockStar SoC: Kirkwood 88F6281_A0 Model: Seagate FreeAgent Dockstar DRAM: 128 MiB MMC: mvsdio@90000: 0 Loading Environment from nowhere... OK In: serial Out: serial Err: serial Model: Seagate FreeAgent Dockstar Net: eth0: ethernet-controller@72000 88E1116 Initialized on ethernet-controller@72000 Hit any key to stop autoboot: 0 resetting USB... Bus ehci@50000: USB EHCI 1.00 scanning bus ehci@50000 for devices... 2 USB Device(s) found scanning usb for storage devices... 0 Storage Device(s) found No storage devices, perhaps not 'usb start'ed..? Card did not respond to voltage select! : -110 Device 0: Model: WDC WD10JPVX-22JC3T0 Firm: 01.01A01 Ser#: WD-WX61E14X1081 Type: Hard Disk Supports 48-bit addressing Capacity: 953869.7 MB = 931.5 GB (1953525168 x 512) ... is now current device ** Searching /boot/uEnv.txt in sata 0 ... ** 1949 bytes read in 50 ms (37.1 KiB/s) ** Environment successfully imported *** Scanning devices... Testing sata 0... 1 bytes read in 13 ms (0 Bytes/s) Found bootable drive on sata 0 loading uImage ... 5472984 bytes read in 116 ms (45 MiB/s) loading uInitrd ... 9710443 bytes read in 184 ms (50.3 MiB/s) loading DTB /boot/dts/kirkwood-dockstar.dtb ... 10297 bytes read in 51 ms (196.3 KiB/s) ## Booting kernel from Legacy Image at 00800000 ... Image Name: Linux-5.14.9-kirkwood-tld-1 Created: 2021-11-19 15:35:55 UTC Image Type: ARM Linux Kernel Image (uncompressed) Data Size: 5472920 Bytes = 5.2 MiB Load Address: 00008000 Entry Point: 00008000 Verifying Checksum ... OK ## Flattened Device Tree blob at 01c00000 Booting using the fdt blob at 0x1c00000 Loading Kernel Image Loading Device Tree to 07b6c000, end 07b71838 ... OK Starting kernel ... Uncompressing Linux... done, booting the kernel.
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... November 29, 2021 12:41AM |
Admin Registered: 13 years ago Posts: 18,821 |
> CONFIG_LEGACY_IMAGE_FORMAT=y > CONFIG_SUPPORT_RAW_INITRD=y >
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... November 29, 2021 02:04AM |
Registered: 2 years ago Posts: 56 |
## Booting kernel from Legacy Image at 00800000 ... Image Name: Linux-5.14.9-kirkwood-tld-1 Created: 2021-11-19 15:35:55 UTC Image Type: ARM Linux Kernel Image (uncompressed) Data Size: 5472920 Bytes = 5.2 MiB Load Address: 00008000 Entry Point: 00008000 Verifying Checksum ... OK Wrong Ramdisk Image Format Ramdisk image is corrupt or invalid resetting ...
common/image-board.cThe code below CONFIG_SUPPORT_RAW_INITRD is the only case that needs the length argument:
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... November 29, 2021 05:09PM |
Admin Registered: 13 years ago Posts: 18,821 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 01, 2021 03:10AM |
Registered: 2 years ago Posts: 56 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 01, 2021 09:04PM |
Admin Registered: 13 years ago Posts: 18,821 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 01, 2021 11:07PM |
Registered: 2 years ago Posts: 56 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 02, 2021 05:35AM |
Registered: 11 years ago Posts: 1,303 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 02, 2021 06:35AM |
Registered: 2 years ago Posts: 56 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 02, 2021 09:33PM |
Admin Registered: 13 years ago Posts: 18,821 |
Quote
Wiring 400MHz signals is no joke, it's a very complex thing, not like connecting few leds and buttons
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 03, 2021 06:11AM |
Registered: 11 years ago Posts: 1,303 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 03, 2021 06:25AM |
Registered: 2 years ago Posts: 56 |
Re: Dockstar mods: SATA, SD, 256MB RAM, Compiling/Modding U-boot; kernel DTB... December 04, 2021 07:51AM |
Registered: 2 years ago Posts: 56 |
root@debian:~# memtester 208 got 208MB (218103808 bytes), trying mlock ...locked. Loop 1: Stuck Address : ok Random Value : ok Compare XOR : ok Compare SUB : ok Compare MUL : ok Compare DIV : ok Compare OR : ok Compare AND : ok Sequential Increment: ok Solid Bits : ok Block Sequential : ok Checkerboard : ok Bit Spread : ok Bit Flip : ok Walking Ones : ok Walking Zeroes : ok 8-bit Writes : ok 16-bit Writes : ok
top - 06:19:01 up 9 min, 1 user, load average: 0.80, 0.94, 0.57 Tasks: 76 total, 1 running, 75 sleeping, 0 stopped, 0 zombie %Cpu(s): 1.3 us, 29.0 sy, 0.0 ni, 54.7 id, 0.0 wa, 0.0 hi, 15.0 si, 0.0 st MiB Mem : 235.9 total, 2.9 free, 22.7 used, 210.3 buff/cache MiB Swap: 2048.0 total, 2048.0 free, 0.0 used. 204.2 avail Mem
